The Cobra had a very short list of options which included
13C: Flip up open air roof or most commonly known as a sunroof. Cost $355.00
585: Premium AM/FM Stereo CD player. Cost $629.00
217: 4 way power drivers seat. Cost $183.00
57Q: Electric heated rear window defroster. Cost $170.00
C: Leather seating surfaces which were only available in opal gray. Cost $523.00
41H: Engine block heater. Cost $20.00
Cobra R Competition Option. Cost $7,205.00
A super sound system was listed in the sales brochure but was not installed on any production vehicle sold to the
public.
Colors/Trim
There were only 3 exterior color options available for the 93 Cobra. They include Black, Red and Teal. There is
technical information to support a non clear coated version of Vibrant red only of which found their way on 9
Cobra's. Exterior color codes were:
UA: Black Clearcoat
RD: Teal Metallic Clearcoat
ES: Vibrant Red Clearcoat
EY: Vibrant Red non Clearcoat
There were 2 colors available for the 93 Cobra which were opal gray and black. Only opal gray was available in
leather. Interior color codes are as follows:
C6: Opal gray leather
D6: Opal gray cloth
DJ: Black cloth
G6: Lowback Opal gray cloth seats only available with the 93 Cobra R versions.
Of the 5100 total 93 Cobra's produced, here is the breakdown of exterior and interior color combinations produced:
Total 93 Cobra's produced in Black were 1,854 in which 448 had black cloth, 327 had gray cloth and 1,079 had gray
leather
Total 93 Cobra's produced in Red including the Cobra R versions were 1,891 in which 362 had black cloth, 522 had
gray cloth and 1,007 had gray leather.
Total 93 Cobra's produced in Teal were 1,355 in which 185 had black cloth, 368 had gray cloth and 802 had gray
leather.
The rarest color combination is the Teal Cobra with black cloth interior.
Engine Specifications
The 1993 Cobra came with a modified 5.0L engine with GT-40 heads and GT-40 cast aluminum intake manifold along with
a new camshaft. Here are some specs for this engine:
Cylinder heads:
GT-40 heads previously sold by Ford Motorsports SVO with 1.84 intake and 1.54 exhaust valves. Heads were milled
from 64cc down to 62.5 cc to raise the compression ratio a bit although the official compression ratio is 9.0:1 and
were topped off with a set of Crane 1.7 ratio full roller rockers. Heads used a pedestal type of mounting system
for the rockers. Part number for the cylinder heads is F3ZZ-6049-B up till 04/13/93 and F4ZZ-6049-B after date
04/13/93
Camshaft:
Ford designed a new camshaft grind to bring back some of the low end torque that was now lost using these higher
flowing cylinder heads. Part number for the cam is F3ZE-6250-CA. Specs are as follows:
Intake/Exhaust duration in degrees of crankshaft rotation: 270/270 and at 0.050 lift 209/209
Intake/Exhaust lift at valve with 1.7 rocker ratio: 0.479/0.479"
Lobe separation is 118.3 degrees with 115 intake lobe center and a 121.5 exhaust lobe center.
Timing events at 0.050 lift are:
Intake: (BTDC):-10.5 / (ABDC): 39.5
Exhaust: (BBDC): 46.0 / (ATDC): -17.0
