2012 Mazda 3 Hatch Touring Bose Audio Bluetooth Very Clean Salvage Title Sunroof on 2040-cars

Auto blog

Mazda patent shows rotary placement in complex AWD hybrid layout

If we were playing alt-powertrain Bingo, a recent Mazda patent application filed in Japan would be one or two letters from victory. What's exciting about the patent, discovered by Japanese outlet T's Media via Motor Trend, is that while it makes a case for an internal combustion engine of any configuration, one of the drawings showing a rotary engine. The wild bit is that the whole powertrain comprises the ICE, a transaxle, two tiny in-wheel electric motors turning the front wheels, a third electric motor in the driveline, a capacitor, a lithium-ion battery, and three inverters. Motor Trend parsed the mechanics, and the way it reads, Doc Brown couldn't have done a better job. The rotary engine at the front turns the rear wheels, but not directly. Instead of a flywheel on back of the engine, the drawing shows a 25-kW electric motor and an inverter, then a driveshaft running to the transaxle. Along the axis of the transmission tunnel in a normal car, between the inverter and the transaxle, lies a 3.5-kWh battery running at 48 volts. MT writes that the electric motor can add its output to the ICE output to drive the rear wheels, or the e-motor can turn the rear axle on its own. Up front, two inverters and a double-layer capacitor join the ICE in the engine bay. The capacitor and tiny hub motors in the front wheels run at 120 volts, a higher voltage than the rest of the electrical system, so that the small in-wheel motors can generate the same torque as a larger motor running at a lower voltage. The AWD system acts on-demand. Given the signal, the capacitors discharge their energy to the wheel motors, and recover energy from braking. When the capacitors are at full charge, they send excess regen energy to the lithium-ion battery; conversely, the battery can recharge the capacitors when they're low and the front hub motors need power. The patent explains that the ICE works with the rear e-motor to drive the rear wheels at low speeds, the front motors called on to "generate an output only when a large output is required in the high vehicle speed range." The rather complicated system is focused on providing the benefits of a hybrid system and all-wheel drive, but at lower weight than one would expect. A rotary serves due to its compactness, but one of the drawings shows an engine with a V layout. Hub motors get dinged for adding unsprung weight, hence the small motors here.

50 engineers kept the rotary alive at Mazda for 8 years

The Mazda RX-Vision concept is one of the standouts at this year's Tokyo Motor Show thanks to a drop-dead gorgeous design and a revival of the Wankel engine. The fact that the rotary is still in development at Mazda is thanks to a dedicated group of 50 engineers. According to Automotive News, their dream for the last eight years has been to bring this storied engine design back to the street. It won't be easy. Because of its design, the rotary suffers from poor fuel economy and high emissions. Making the challenge even harder, Mazda reportedly only gives them a small budget, but they continue to chip away at the problem. "These 50 engineers want to develop the rotary engine, therefore they joined Mazda," company research and development boss Kiyoshi Fujiwara told AN. "If I stop the rotary engine, probably they want to leave." For the Skyactiv-R under the RX-Vision's svelte hood, the team reportedly started from the 16X rotary project. Dating back to 2007, that 1.6-liter engine was supposed to improve torque and fuel economy thanks in part to direct injection. After additional development, insiders even suggested that the engineers might have finally solved the powerplant's issues. However, Mazda never put the mill into production, and the RX-8 remains the company's last Wankel-powered model to be offered in showrooms. "We have a dream that one day, this design with a rotary engine will achieve a level that customers will accept," CEO Masamichi Kogai said to AN. Mazda is quite clear that the RX-Vision might never go on sale without a suitable rotary. Although if it does see production, the coupe would likely use a stiffened version of the Miata's chassis, AN reports. Before anyone can place an order, these 50 determined engineers still have a lot of work ahead of them. Related Video:

Tougher than steel: Wood pulp could make lighter auto parts

KYOTO, Japan — The global push among carmakers to make ever lighter vehicles is leading some auto suppliers in Japan to turn to what seems like an unlikely steel substitute — wood pulp. Japanese researchers and auto component makers say a material made from wood pulp weighs just one-fifth of steel and can be five times stronger. The material - cellulose nanofibers — could become a viable alternative to steel in the decades ahead, they say, although it faces competition from carbon-based materials, and remains a long way from being commercially viable.> Related: Jay Leno drives the Renew cannabis car — hemp you can't dent Reducing the weight of a vehicle will be critical as manufacturers move to bring electric cars into the mainstream. Batteries are an expensive but vital component, so a reduction in car weight will mean fewer batteries will be needed to power the vehicle, saving on costs. "Lightweighting is a constant issue for us," said Masanori Matsushiro, a project manager overseeing body design at Toyota. "But we also have to resolve the issue of high manufacturing costs before we see an increased use of new, lighter-weight materials in mass-volume cars."A NEW PROCESS Researchers at Kyoto University and major parts suppliers such as Denso Corp, Toyota's biggest supplier, and DaikyoNishikawa Corp, are working with plastics incorporated with cellulose nanofibers — made by breaking down wood pulp fibers into several hundredths of a micron (one thousandth of a millimeter). Cellulose nanofibers have been used in a variety of products ranging from ink to transparent displays, but their potential use in cars has been enabled by the "Kyoto Process," under which chemically treated wood fibers are kneaded into plastics while simultaneously being broken down into nanofibers, slashing the cost of production to roughly one-fifth that of other processes. "This is the lowest-cost, highest-performance application for cellulose nanofibers, and that's why we're focusing on its use in auto and aircraft parts," Kyoto University Professor Hiroaki Yano, who is leading the research, told Reuters in an interview. The university, along with auto parts suppliers, are currently developing a prototype car using cellulose nanofiber-based parts to be completed in 2020.
