2007 Mazda 3 S Sport on 2040-cars

Auto blog

Mazda patent shows rotary placement in complex AWD hybrid layout

If we were playing alt-powertrain Bingo, a recent Mazda patent application filed in Japan would be one or two letters from victory. What's exciting about the patent, discovered by Japanese outlet T's Media via Motor Trend, is that while it makes a case for an internal combustion engine of any configuration, one of the drawings showing a rotary engine. The wild bit is that the whole powertrain comprises the ICE, a transaxle, two tiny in-wheel electric motors turning the front wheels, a third electric motor in the driveline, a capacitor, a lithium-ion battery, and three inverters. Motor Trend parsed the mechanics, and the way it reads, Doc Brown couldn't have done a better job. The rotary engine at the front turns the rear wheels, but not directly. Instead of a flywheel on back of the engine, the drawing shows a 25-kW electric motor and an inverter, then a driveshaft running to the transaxle. Along the axis of the transmission tunnel in a normal car, between the inverter and the transaxle, lies a 3.5-kWh battery running at 48 volts. MT writes that the electric motor can add its output to the ICE output to drive the rear wheels, or the e-motor can turn the rear axle on its own. Up front, two inverters and a double-layer capacitor join the ICE in the engine bay. The capacitor and tiny hub motors in the front wheels run at 120 volts, a higher voltage than the rest of the electrical system, so that the small in-wheel motors can generate the same torque as a larger motor running at a lower voltage. The AWD system acts on-demand. Given the signal, the capacitors discharge their energy to the wheel motors, and recover energy from braking. When the capacitors are at full charge, they send excess regen energy to the lithium-ion battery; conversely, the battery can recharge the capacitors when they're low and the front hub motors need power. The patent explains that the ICE works with the rear e-motor to drive the rear wheels at low speeds, the front motors called on to "generate an output only when a large output is required in the high vehicle speed range." The rather complicated system is focused on providing the benefits of a hybrid system and all-wheel drive, but at lower weight than one would expect. A rotary serves due to its compactness, but one of the drawings shows an engine with a V layout. Hub motors get dinged for adding unsprung weight, hence the small motors here.

We go Unplugged to celebrate Mazda Miata Month

Chances are good that you, loyal Autoblog reader, have long since chosen to follow us on Twitter and 'like' us on Facebook. (If you haven't, feel free to take a second and do so right now.) Anyway, if you're one of our social media posse, you might have already heard that we're smack dab in the middle of Miata Month. We've gotten Mazda to loan us a couple of MX-5 Miatas, allowing us to say a protracted, tear-filled goodbye to the current generation (NC) of the beloved roadster, just before it exits stage right and ushers in the next generation.
You'll see a few more Miata Month items here on Autoblog after we've said our final farewell, but we absolutely wanted to make sure we created some great video evidence of our month, as well. Right down below, then, in its unfiltered-audio splendor, is the Autoblog Unplugged version of the 2015 Mazda MX-5 Miata PRHT. Your author had a pretty great time wringing out the roadster for the creation of our short vid, and we really hope you dig listening along.

Mazda3 with Skyactiv-X engine technology caught testing in the wild

Sometimes, automakers are fine with their mules coming under the watchful lenses of spy shooters. Proof of this can be seen plastered across the bodysides of the Mazda3 mule you see above. Clearly, Mazda wants the world to know that engineers are working hard on the company's so-called Skyactiv-X engine technology so badly that it's created a custom matte black vinyl wrap for its test mules. Clever. Expect to see this sweet new engine tech in the 2019 Mazda3. This SCCI, or Spark Controlled Compression Ignition system holds tremendous potential to boost the efficiency of gasoline-powered engines by 20-30 percent, thereby matching the fuel economy of a comparatively sized diesel engine. As an added bonus, torque figures are expected to jump a similar amount. Besides the placard-sized stickers, there isn't much to see here. The car is clearly a Mazda3 hatchback, though the fenders are punched out a bit and the fuel door is modified from stock. We'd wager that future prototypes will wear a lot more camouflage to cover up next-gen bodywork. In other words, stay tuned. Related Video: Featured Gallery Mazda3 Skyactiv-X: Spy Shots View 9 Photos Green Spy Photos Mazda Fuel Efficiency Technology Emerging Technologies Hatchback skyactiv mazda mazda3 skyactiv-x
